mmo titanium تار anode
ڪوٽنگ جي جوڙجڪ: ٽي، رو، آئر، پي ٽي، ٽا، ايس اين، ڪو
ڌاتو مواد: 8 ~ 25 گرام / ㎡
ڪوٽنگ جي ٿولهه: 8~12㎛
ڪم ڪندڙ گرمي پد: ＜60 ℃
ڪم ڪندڙ زندگي: ~ 5 سال
Material:GR1 Ti
Production process:Electrolytic organic
ٽائيٽينيم جو مواد: 99.99٪
MMO Titanium Wire Anode - Premium DSA Solutions for Corrosion Protection
اسان mmo titanium تار anode combines advanced coating technology with high-purity GR1 titanium substrate to deliver enterprise-grade performance. With 8-25g/㎡ metal content and coating thickness of 8-12µm, your system benefits from a working life exceeding 5 years. Manufactured by Baoji City ShenAo Metal Materials Co., Ltd. since 2008, each anode maintains 99.99% titanium purity and operates stably under 60°C. Our proven explosive welding technology and active coating process ensure consistent current distribution, low overpotential, and exceptional durability in highly corrosive environments—perfect for your ICCP systems and specialized electrolysis applications.
What Makes Our MMO Titanium Wire Anode Different?
You're probably dealing with the frustration of traditional anodes. Graphite anodes consume too quickly. Lead-alloy options pollute your environment. Ceramic anodes break under mechanical stress.
That's where our product changes everything.
The secret lies in our catalytic Mixed Metal Oxide coating. We apply a precise crystalline layer containing Iridium, Ruthenium, and Tantalum onto premium titanium wire. This coating activates the titanium surface, transforming it into a highly efficient anode.
Your system gets stable geometry. Current flows consistently. No dimensional changes over time. No unexpected failures.
The titanium substrate forms a protective oxide film under anodic polarization. This ensures current exits only through our catalytic MMO coating—exactly where you need it.
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
ٽيڪنيڪل Specifications
|
سميجي
|
Specification
|
|
دستياب فارم
|
پليٽ، ٽيوب، ميش، راڊ، تار، پٽي، ڪسٽم شڪلون
|
|
ڪوٽنگ جي جوڙجڪ
|
تي، رو، اِر، پِٽ، ٽا، سِن، ڪو
|
|
ڌاتو جو مواد
|
8 ~ 25 گرام/㎡
|
|
ڪوٽنگ جو موٽ
|
8~12µm
|
|
ڪمائيء جي گرمي
|
<60 ℃
|
|
خدمت زندگي
|
> 5 سال
|
|
ذيلي ذخيرو مواد
|
GR1 ٽائيٽينيم
|
|
ٽائيٽينيم جي پاڪائي
|
99.99٪
|
|
پيداوار جو عمل
|
Electrolytic organic
|
|
موجوده کثافت جي صلاحيت
|
Up to 1000 A/m² (seawater)
|
Key Applications You'll Benefit From
متاثر ٿيل موجوده ڪيٿولڪ تحفظ (ICCP)
Protect your underground pipelines, storage tanks, and marine structures. Our mmo titanium wire anodes deliver consistent protection current for decades.
سمنڊ جو پاڻي ۽ برائن اليڪٽرولائيزس
Need chlorine advancement? Our Ru-Ir coating definition gives ideal execution in high-chloride environments.
Soil and Freshwater Protection
Working with low-chloride conditions? We offer Ir-Ta coating variations particularly outlined for oxygen advancement in acidic environments.
لچڪدار لڳائڻ
The wire arrange permits you to coil or shape the anode for contract spaces. You get mechanical adaptability without relinquishing electrochemical execution.
 |
 |
 |
 |
 |
 |
 |
پيداوار جي پيداوار جي عمل
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
شين آو ڌاتو مواد ڇو چونڊيو؟
17 شاندار تخليق جو هڪ ڊگهو وقت
Since 2008, we've been culminating bimetallic dangerous welding and dynamic coating forms. Our area in China's Titanium Valley gives us unmatched get to to premium materials.
ثابت ٿيل معيار جا معيار
Every item meets strict prepare controls. We take after ASTM B348 for substrate keenness and keep up comprehensive quality administration systems.
توهان جي ضرورتن لاءِ ڪسٽمائيزيشن
Wire distance across from 1.0mm to 3.0mm? Uncommon coating details? We customize details based on your current necessities and establishment constraints.
تيز، مضبوط پهچائڻ
Small clump testing or large-scale production—we convey on time. Our built up organizations with hundreds of hardware producers guarantee supply chain solidness.
 |
 |
 |
 |
 |
 |
 |
 |
 |
ايپليڪيشن انڊسٽريز
 |
 |
 |
 |
 |
 |
 |
 |
اسان جو فڪري
اسان جا پيٽنٽ ۽ اعزاز
سنڌ
اسان جي پيڪنگنگ
 |
 |
 |
 |
 |
 |
 |
 |
 |
 |
وچان وچان سوال ڪرڻ
What is the distinction between Ru-Ir and Ir-Ta coatings for the products?
Ru-Ir coatings work best for chlorine advancement in seawater or brine situations. Ir-Ta coatings are optimized for oxygen advancement in acidic or low-chloride conditions like soil or freshwater. Select based on your electrolyte composition.
Can the anode be recoated?
Yes. Once the coating depletes, you can chemically strip the titanium substrate and apply new coating. This recoating capability altogether diminishes your long-term lifecycle costs.
How does temperature influence anode performance?
Our standard anodes stay steady up to 60°C in most electrolytes. Require higher temperature resistance? We can define specialized coatings. Fair remember—excessive warm quickens coating consumption.
Why utilize titanium substrate instep of other metals?
Titanium shapes a defensive, non-conductive oxide film beneath anodic polarization. This passivation layer guarantees current exits as it were through the catalytic MMO coating—maintaining effectiveness and avoiding substrate erosion.
What wire diameters are available?
Common diameters range from 1.0mm to 3.0mm. We manufacture custom diameters based on your required current output and the mechanical strength needed for installation.
اسان سان رابطو ڪريو
Ready to upgrade your cathodic protection system with mmo titanium تار anode؟ اسان جي ٽيم سان رابطو ڪريو تي zh@baojiti.com.cn ٽيڪنيڪل وضاحتن ۽ قيمت لاءِ.
